MSI Workstation 10TK-1025FR RAM upgrade specifications
MSI WS75 10TK-1025FR workstation specifications detail DDR4-SDRAM memory upgrade capacity. The laptop contains 2x SO-DIMM slots supporting maximum RAM of 64 GB total capacity. Memory modules operate at 2666 MHz frequency with SO-DIMM form factor. Upgrade specifications define compatible DDR4 memory modules for the MSI workstation series, enabling users to expand system memory according to slot availability and maximum capacity constraints.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 07 February 2021 |
Additional Notes
- The presence of 2 SO-DIMM slots signifies a dual-channel memory architecture which requires matching module pairs to achieve peak memory bandwidth.
- The MSI Workstation 10TK-1025FR internal hardware allows for a 32 GB module in each slot to reach the maximum supported capacity.
- Upgrading with memory modules rated higher than 2666 MHz results in automatic downclocking to the system bus speed limit.
- Small Outline Dual In-line Memory Modules are necessary due to physical clearance constraints within the chassis compared to desktop hardware.
- Replacing existing modules requires complete removal of factory hardware when both slots are populated as there no additional vacant lanes.
- Mixing modules of different latencies forces the system to operate at the timings of the slowest installed stick.
- Accessing the internal memory slots often requires the removal of the bottom panel which might involve breaking a factory seal depending on regional warranty policies.
