ACER TravelMate P259-G2-MG-5215 RAM upgrade specifications
The Acer TravelMate P2 series model P259-G2-MG-5215 features DDR4-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 32 GB. Compatible memory operates at 2133 MHz frequency. The laptop accommodates SO-DIMM form factor modules, enabling users to upgrade existing RAM configurations through the available slots to enhance system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2133 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2133 (PC4-17064) |
| Bandwidth | 17.1 GB/s |
| Laptop Release date | 10 August 2017 |
Additional Notes
- Dual channel architecture requires matching memory capacities in both SO-DIMM slots to maximize memory controller throughput.
- Physical access to internal components involves removing the entire lower chassis panel which may necessitate careful handling of fragile plastic retention clips.
- Higher frequency DDR4 modules will automatically downclock to 2133 MHz due to chipset firmware limitations.
- The 32 GB capacity threshold limits the system to using 16 GB high density modules per slot.
- Latency timings are governed by the slowest installed module if mismatched sticks are used simultaneously.
- Support for 2 SODIMM slots allows for a staggered upgrade path where one factory module remains while a larger capacity stick is added to the vacant slot.
- The use of 1.2V DDR4 standard ensures lower thermal output compared to legacy DDR3L systems during sustained memory intensive tasks.
- Compatibility is restricted to non-ECC unbuffered modules as the mobile chipset does not support error correction code memory.
