ACER TravelMate TMP214-52-539B RAM upgrade specifications
ACER TravelMate P2 series model TMP214-52-539B features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum capacity of 32 GB RAM. Compatible memory modules operate at 2133 MHz frequency using SO-DIMM form factor. RAM upgrade configuration allows expansion from factory specifications to maximum supported capacity through available memory slots on this laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2133 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2133 (PC4-17064) |
| Bandwidth | 17.1 GB/s |
| Laptop Release date | 04 February 2021 |
Additional Notes
- Dual channel architecture requires matching module pairs to optimize memory bandwidth and reduce system latency during heavy multitasking.
- The ACER TravelMate TMP214-52-539B utilizes a removable module design that allows for total hardware replacement rather than relying on non-upgradeable soldered chips.
- Installing modules with frequencies higher than 2133 MHz will result in automatic downclocking to match the native motherboard speed limitations.
- Reaching the 32 GB threshold necessitates the use of two 16 GB sticks since the BIOS architecture does not support a single 32 GB module per slot.
- The SO-DIMM form factor restricts hardware selection to 260 pin laptop modules and prevents the use of full sized desktop memory sticks.
- Accessing the internal slots requires removal of the bottom chassis panel which may involve piercing factory seal stickers in certain regions.
- Integrated graphics performance scales directly with memory capacity because the system allocates a portion of the physical RAM for video processing tasks.
