ACER TravelMate TMP214-52-59FQ RAM upgrade specifications
ACER TravelMate P2 Series model TMP214-52-59FQ features DDR4-SDRAM memory upgrades. The laptop contains 2x SO-DIMM slots for memory expansion. Maximum RAM capacity reaches 32 GB total. Compatible memory modules operate at 2133 MHz frequency. SO-DIMM form factor specifications apply to all upgrade components. Memory upgrade options enable increased system performance for the TravelMate P2 series platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2133 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2133 (PC4-17064) |
| Bandwidth | 17.1 GB/s |
| Laptop Release date | 04 February 2021 |
Additional Notes
- The presence of 2 physical SO-DIMM slots allows for dual-channel memory configurations which doubles the theoretical bandwidth compared to single-channel setups.
- The ACER TravelMate TMP214-52-59FQ requires 260-pin modules as the small outline form factor is incompatible with desktop DIMM slots.
- Installing modules with frequencies higher than 2133 MHz results in an automatic underclocking to match the system bus limitation.
- Maximum capacity constraints imply that the motherboard firmware will not recognize individual modules larger than 16 GB per slot.
- Upgrading to the 32 GB limit necessitates the removal of existing modules if both slots are currently occupied by lower-capacity hardware.
- Memory latency and system responsiveness depend on matching the CAS latency of both sticks to ensure stability and prevent boot failures.
- The hardware architecture supports non-ECC unbuffered memory only which excludes the use of server-grade registered modules.
