ACER TravelMate TMP259-M-397F RAM upgrade specifications
The ACER TravelMate P2 series TMP259-M-397F supports DDR4-SDRAM memory upgrades with 2x SO-DIMM slots for maximum capacity of 32 GB total RAM. Compatible memory modules operate at 2133 MHz frequency using the SO-DIMM form factor. Specifications enable users to upgrade memory capacity by installing additional DDR4-SDRAM modules in available slots to enhance system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2133 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2133 (PC4-17064) |
| Bandwidth | 17.1 GB/s |
| Laptop Release date | 25 October 2019 |
Additional Notes
- Dual channel mode is only achievable when both slots contain matching modules to facilitate parallel data processing.
- The ACER TravelMate TMP259-M-397F architecture requires 260 pin modules specifically designed for mobile chipsets.
- Installing modules with frequencies higher than 2133 MHz will result in automatic downclocking to the motherboard limit.
- Internal access for memory replacement necessitates the removal of the bottom chassis panel which may involve piercing factory seal stickers.
- Single module configurations create a memory bandwidth bottleneck that negatively impacts integrated graphics performance.
- System stability is contingent on using 1.2V low voltage modules as standard desktop voltage variants are incompatible with the power delivery system.
- Utilization of the 32 GB limit requires 2 16 GB high density sticks as the motherboard does not support 32 GB in a single slot.
