ASUS ROG GV601VU-DS91T-CA RAM upgrade specifications
ASUS ROG Flow X16 GV601VU-DS91T-CA laptop features DDR5-SDRAM memory specifications supporting upgrade configurations. The device contains 2x SO-DIMM slots for memory expansion. Maximum RAM capacity reaches 64 GB total. Compatible memory modules operate at 4800 MHz frequency. Upgrades utilize SO-DIMM form factor modules. Specifications enable performance enhancement through memory expansion within the established capacity and slot limitations.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- DDR5-4800 modules operate at JEDEC standard voltage (1.1V), establishing baseline compatibility with the ASUS ROG GV601VU-DS91T-CA without requiring manufacturer-specific binning or overclocking profiles.
- The 2-slot SO-DIMM configuration necessitates dual-channel population for optimal memory bandwidth utilization; single-slot installation reduces effective throughput by approximately 50 percent regardless of module capacity.
- Maximum capacity of 64 GB requires both slots filled with 32 GB modules; this configuration consumes the physical limit and eliminates upgrade headroom for future capacity expansion within the existing slot architecture.
- SO-DIMM form factor constrains module selection to laptop-grade memory; desktop DDR5 DIMM modules are physically incompatible and cannot be force-fitted without permanent connector damage.
- DDR5-4800 frequency rating establishes the memory controller's maximum supported speed; higher-frequency variants (5200+ MHz) may not train reliably and could trigger boot failures or automatic downclocking to 4800 MHz by the BIOS.
- Warranty coverage typically remains valid during RAM replacement when using non-ECC, non-overclocked DDR5 modules meeting the 4800 MHz specification and voltage requirements; third-party validation documentation may be requested for claim processing.
- Existing memory modules cannot be repurposed in desktop systems without DDR5 SO-DIMM adapter cards, which introduce latency penalties and are not recommended for performance-critical applications.
