ASUS ROG GV601VU-NF022W RAM upgrade specifications
ASUS ROG Flow X16 GV601VU-NF022W laptop features DDR5-SDRAM memory configuration with two SO-DIMM slots supporting maximum capacity of 64 GB. Memory upgrade specifications include DDR5 modules operating at 4800 MHz frequency. Compatible RAM modules must utilize SO-DIMM form factor for proper installation in available slots. Specifications enable performance-oriented memory expansion for enhanced multitasking and demanding applications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 February 2023 |
Additional Notes
- Dual channel architecture in the ASUS ROG GV601VU-NF022W requires matching module pairs to achieve peak memory bandwidth and minimize data processing latency.
- The absence of soldered memory on the motherboard allows for the total replacement of factory modules rather than relying on a single expansion slot.
- Upgrading to modules with speeds exceeding 4800 MHz will result in automatic downclocking to the system bus limit governed by the processor architecture.
- Physical installation is restricted to 262 pin hardware interfaces as the motherboard lacks compatibility with older DDR4 or smaller soldered LPDDR standards.
- High capacity 32 GB modules are necessary in both slots to reach the thermal and electrical ceiling of the 64 GB maximum threshold.
- The use of SO-DIMM slots implies that memory stability depends on proper seating within the tension clips to prevent intermittent boot failures or system crashes.
- Voltage requirements for DDR5 are lower than previous generations which reduces internal heat generation but necessitates the use of specific 1.1V compatible components.
