ASUS ROG G614JI-N4183X RAM upgrade specifications
The ASUS ROG Strix G16 G614JI-N4183X features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 32 GB. Compatible RAM operates at 4800 MHz frequency. The laptop memory configuration utilizes SO-DIMM form factor modules. Specifications indicate upgrade slots accommodate DDR5 memory technology for enhanced performance in the G614JI-N4183X gaming platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 16 January 2023 |
Additional Notes
- The dual-channel configuration in the ASUS ROG G614JI-N4183X requires two identical modules to reach peak memory bandwidth for high-frame-rate gaming scenarios.
- The specified capacity limit indicates a motherboard firmware restriction that prevents the addressing of high-density 32 GB or 48 GB single sticks.
- Lower latency modules with tight timings provide better performance gains than increasing speed beyond the supported 4800 MHz due to processor memory controller locks.
- Upgrading requires the removal of the entire base panel which involves navigating delicate internal ribbon cables for the integrated lighting zones.
- Heat spreaders on aftermarket memory must maintain a slim profile to avoid physical interference with the bottom chassis cover or internal cooling heat pipes.
- Data transfer rates will automatically downclock to the lowest common denominator if mismatched frequency modules occupy the available ports.
- The absence of soldered memory ensures a fully modular path for replacing faulty hardware without requiring a mainboard swap.
