ASUS ROG G614JZ-N3059W RAM upgrade specifications
The ASUS ROG Strix G16 G614JZ-N3059W features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 32 GB total RAM. Compatible memory modules operate at 4800 MHz frequency. The laptop accommodates SO-DIMM form factor modules for memory expansion and upgrades. Specifications indicate dual-slot configuration enabling memory capacity expansion from factory-installed configuration to maximum supported capacity of 32 GB DDR5-SDRAM.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 June 2023 |
Additional Notes
- Dual channel architectural symmetry is maintained by utilizing both available slots to bypass single channel bandwidth limitations during intensive rendering or gaming.
- The maximum capacity cap indicates a firmware or chipset limitation that prevents the utilization of 32 GB or 48 GB high density modules in a single slot.
- The ASUS ROG G614JZ-N3059W requires SO-DIMM modules with integrated Power Management Integrated Circuits to handle voltage regulation directly on the memory PCB.
- Standard 4800 MHz frequency modules operate at JEDEC default profiles meaning XMP or DOCP manual configuration is unnecessary for reaching advertised speeds.
- Future memory expansions require the removal of existing modules because the system lacks vacant slots for additive upgrades.
- Non ECC unbuffered memory modules are mandatory as the internal controller does not support error correcting code protocols for data integrity.
- Thermal management constraints within the chassis suggest avoiding modules with thick integrated heat spreaders to ensure physical clearance and proper airflow.
