ASUS ROG G713QR-HG107T RAM upgrade specifications

ASUS G713QR-HG107T ASUS G713QR-HG107T ASUS G713QR-HG107T ASUS G713QR-HG107T ASUS G713QR-HG107T

The ASUS ROG Strix G17 G713QR-HG107T laptop features DDR4-SDRAM memory with 2x SO-DIMM upgrade slots. Maximum RAM capacity reaches 32 GB total, supporting 3200 MHz frequency specifications. Compatible memory upgrades utilize the SO-DIMM form factor for this gaming-class mobile workstation. Current configuration and additional slot specifications determine available upgrade capacity options.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency3200 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-3200 (PC4-25600)
Bandwidth25.6 GB/s
Laptop Release date13 May 2021

Additional Notes

  • The ASUS ROG G713QR-HG107T accommodates only 2 SO-DIMM slots, meaning both slots must be populated to reach the 32 GB ceiling; a single module cannot achieve maximum capacity alone.
  • DDR4-3200 modules represent the performance baseline; faster DDR4 variants (3600 MHz or higher) may operate at reduced 3200 MHz speeds due to BIOS memory profile limitations on this chipset, resulting in no performance gain from premium-speed purchases.
  • SO-DIMM form factor requires low-profile memory modules; standard UDIMM desktop memory is physically incompatible and cannot be force-fitted without chassis damage.
  • Upgrading from any configuration below 32 GB requires removing at least 1 existing module; no "addition-only" upgrade path exists without a second slot becoming available.
  • DDR4 memory availability continues to decline as DDR5 adoption accelerates; sourcing matching pairs of SO-DIMM DDR4-3200 modules within 12-24 months may present supply or pricing challenges for future expansions.
  • Warranty protection during RAM installation depends on ASUS service policy; opening the chassis to access memory slots may void coverage if not performed by authorized technicians, contingent on regional terms.
