ASUS ROG G713QR-HG142T RAM upgrade specifications
The ASUS ROG Strix G17 G713QR-HG142T supports DDR4-SDRAM memory upgrades with 2x SO-DIMM slots for maximum capacity of 32 GB. Compatible RAM modules operate at 3200 MHz frequency. The laptop features SO-DIMM form factor memory specifications, allowing users to upgrade existing memory configurations up to the stated maximum capacity. Specifications indicate support for dual-channel memory architecture on the G713QR-HG142T gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 10 December 2021 |
Additional Notes
- Dual channel mode requires pairs of identical modules to achieve peak memory bandwidth for the Ryzen processor within the ASUS ROG G713QR-HG142T.
- The 32 GB ceiling indicates a limitation in the BIOS or memory controller address space despite the existence of 32 GB single modules.
- Operating at 3200 MHz requires modules to support JEDEC profiles to ensure compatibility without XMP or manual voltage adjustments.
- Internal access for memory replacement necessitates the removal of the bottom chassis panel which involve delicate ribbon cables for the integrated light bar.
- Upgrading to the maximum capacity utilizes both available SO-DIMM slots and prevents further expansion without replacing existing hardware.
- Latency performance depends on the density of the chosen modules as high density 1Rx16 banks can reduce processing throughput compared to 1Rx8 configurations.
- The use of DDR4 technology restricts the system to 1.2V power delivery standards for memory components.
