ASUS ROG G814JI-CS94 RAM upgrade specifications

ASUS G814JI-CS94 ASUS G814JI-CS94 ASUS G814JI-CS94 ASUS G814JI-CS94 ASUS G814JI-CS94

The ASUS ROG Strix G18 G814JI-CS94 features DDR5-SDRAM memory specifications with two SO-DIMM slots available for upgrade capacity. The laptop supports maximum RAM configuration of 32 GB total memory. Memory specifications include DDR5 technology operating at 4800 MHz frequency. Compatible DDR5 SO-DIMM modules enable RAM upgrade possibilities for enhanced multitasking and performance capabilities. The dual-slot configuration allows flexible memory expansion within the 32 GB maximum capacity limitation for this gaming laptop model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR5-SDRAM
Frequency4800 MHz
Maximum RAM32 GB
Voltage1.1V
Number of pins262-pin
InterfacePC5
PC Speed RatingPC5-4800 (PC5-38400)
Bandwidth38.4 GB/s
Laptop Release date10 February 2023

Additional Notes

  • The 2 slot configuration requires the removal of existing modules to reach the maximum capacity since no additional headers remain for expansion.
  • Installing memory with higher clock speeds results in downclocking to 4800 MHz due to firmware limitations on the ASUS ROG G814JI-CS94 motherboard.
  • The dual channel architecture remains dependent on matched pairs to maintain peak memory bandwidth for the processor.
  • Internal heat spreaders on aftermarket SO-DIMM modules must maintain a slim profile to avoid physical interference with the chassis bottom cover.
  • The system relies on the DDR5 internal ECC feature for data integrity as it lacks support for dedicated workstation grade buffered memory.
  • Voltage requirements for replacement modules must align with the standard 1.1V specification to ensure stability without manual BIOS adjustments.
  • The 32 GB ceiling dictates that 16 GB is the maximum density supported per individual slot.
