ASUS ROG G533ZS-LN025W RAM upgrade specifications
The ASUS ROG Strix SCAR 15 G533ZS-LN025W laptop features DDR5-SDRAM memory upgradeable through two SO-DIMM slots. Maximum RAM capacity reaches 64 GB, supporting DDR5 memory modules operating at 4800 MHz frequency. Compatible memory upgrades utilize SO-DIMM form factor for this gaming notebook. Specifications indicate dual-channel memory configuration supporting high-speed DDR5 technology for enhanced performance capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 26 October 2022 |
Additional Notes
- The dual-channel architecture requires paired modules to maximize memory bandwidth and eliminate potential CPU bottlenecks during high-performance tasks.
- Upgrading the ASUS ROG G533ZS-LN025W to 64 GB necessitates the removal of all factory-installed modules because the motherboard lacks additional vacant slots.
- The DDR5 architecture incorporates on-die ECC and power management integrated circuits which reduce the motherboard voltage regulation workload but increase module heat generation.
- Installation of memory with speeds exceeding 4800 MHz will result in automatic downclocking to match the system firmware limitations.
- Physical installation requires a non-conductive pry tool to release the internal chassis clips without damaging the integrated RGB lighting synchronization cables.
- Latency performance depends on choosing modules with matching CAS latency values to prevent the system from defaulting to the slowest shared timing profile.
- The SO-DIMM form factor dictates a maximum height allowance which precludes the use of memory modules equipped with oversized aftermarket heat spreaders.
