ASUS ROG G712LV-EV072T RAM upgrade specifications
The ASUS ROG Strix G712LV-EV072T gaming laptop features DDR4-SDRAM memory upgrade capabilities. The system includes 2x SO-DIMM slots supporting a maximum RAM capacity of 32 GB total. Compatible memory operates at 3200 MHz frequency. Upgrade specifications utilize the SO-DIMM form factor, standard for laptop memory modules. The G712LV-EV072T supports memory expansion through replacement or addition of DDR4 modules within the designated slots to reach maximum specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 19 May 2020 |
Additional Notes
- The ASUS ROG G712LV-EV072T accommodates a maximum of 32 GB total capacity across its 2 SO-DIMM slots, meaning each slot accepts a single 16 GB module at full capacity.
- DDR4-3200 modules operate within JEDEC standard specifications, eliminating compatibility risk with aftermarket memory from reputable manufacturers, though actual frequency negotiation depends on BIOS configuration and processor support.
- SO-DIMM form factor requires low-profile memory modules; standard UDIMM sticks will not fit physically and cannot be force-installed without damaging the socket.
- Upgrading to 32 GB requires either replacing both existing modules with 16 GB units or, if only 1 slot is populated, adding a single 16 GB SO-DIMM to the vacant slot; mixed capacities (such as 8 GB plus 16 GB) function in dual-channel mode but leave 24 GB total installed.
- The 2-slot configuration creates a bandwidth limitation; dual-channel operation maxes out at the combined bandwidth of both DIMMs, leaving no expansion path beyond 32 GB without replacing existing memory.
- Memory speed at 3200 MHz is tied to the processor's IMC (Integrated Memory Controller) capability; BIOS settings may not guarantee 3200 MHz operation on all system configurations, and downclocking to 2666 MHz or 2933 MHz may occur automatically depending on CPU generation and voltage stability.
- RAM replacement qualifies as a user-serviceable component in most ASUS ROG models and does not void hardware warranty, provided modules are installed without physical damage to the system.
