ASUS ROG G712LWS-EV553T RAM upgrade specifications
ASUS ROG Strix G712LWS-EV553T laptop features DDR4-SDRAM memory with two SO-DIMM slots supporting maximum RAM capacity of 32 GB. Memory upgrade specifications indicate compatibility with DDR4 modules operating at 3200 MHz frequency. The SO-DIMM form factor enables RAM expansion for enhanced system performance. Current memory configuration allows upgrade potential to reach maximum capacity specifications through compatible DDR4-SDRAM modules in available slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 28 April 2020 |
Additional Notes
- The ASUS ROG G712LWS-EV553T contains 2 SO-DIMM slots, which means maximum capacity is achieved by populating both slots with 16 GB modules rather than replacing a single module, limiting partial upgrade flexibility.
- DDR4-3200 memory operates at 3200 MHz, which is standard for this generation but does not support higher-frequency DDR4 variants (3600 MHz or 4000 MHz), constraining performance tuning through memory overclocking.
- SO-DIMM form factor is laptop-specific and not interchangeable with desktop DIMM modules, requiring sourcing from mobile memory inventories and typically commanding higher per-gigabyte pricing than standard DIMM equivalents.
- Upgrading beyond the factory configuration to the 32 GB maximum requires both SO-DIMM slots to be populated, leaving no vacant slots for future expansion without removing existing modules.
- The 2-slot architecture creates a memory bandwidth ceiling where dual-channel configuration maxes out at the installed capacity, preventing addition of a third or fourth channel as seen in workstation platforms.
- DDR4-3200 with SO-DIMM packaging incurs higher latency compared to desktop DDR4 due to electrical constraints of the mobile connector type, which may compound performance impacts if paired with high-load applications.
- Warranty coverage for memory upgrades typically remains valid when using manufacturer-approved or certified DDR4-3200 SO-DIMM modules, but installation should be performed according to ASUS service guidelines to preserve coverage.
