ASUS ROG GL503VM-FY113T RAM upgrade specifications
ASUS ROG Strix GL503VM-FY113T RAM upgrade specifications indicate DDR4-SDRAM memory compatibility with 2x SO-DIMM slots supporting maximum capacity of 32 GB. Memory upgrade specifications feature DDR4-2400 MHz frequency support. Compatible RAM modules utilize SO-DIMM form factor for this gaming laptop model. Maximum RAM capacity allows dual-module configuration totaling 32 GB total system memory.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 11 February 2019 |
Additional Notes
- The ASUS ROG Strix GL503VM-FY113T contains 2 SO-DIMM slots with a 32 GB ceiling, permitting maximum configuration of 16 GB per module. Upgrading beyond the factory configuration requires matching DDR4 SO-DIMM modules; desktop DDR4 UDIMM sticks are physically incompatible and will not seat in the laptop's memory slots.
- The 2400 MHz specification defines the memory controller's native speed. Modules rated for faster speeds (2666 MHz, 3000 MHz, 3200 MHz) will operate at 2400 MHz when installed, as the platform lacks support for higher frequency operation. Performance gains from premium-speed memory do not materialize on this hardware.
- Single-channel population (one module installed) triggers a bandwidth penalty relative to dual-channel operation. Installing 2 matching modules enables parallel data access and maximizes memory throughput to the processor. Asymmetrical configurations (mismatched capacities or speeds between slots) force the system to default to the lower specification, reducing effective bandwidth.
- Accessing memory slots typically requires removal of the base panel or keyboard assembly. This procedural step may void the warranty unless performed by authorized service personnel. Verification of the disassembly method through official documentation mitigates warranty risk before opening the chassis.
- The integrated GPU in the 7th-generation Intel processor shares system RAM dynamically. Allocating 64 MB to 512 MB to graphics reduces available memory for applications. This allocation occurs at boot and is not user-adjustable in BIOS on most consumer ROG models, creating an effective usable capacity lower than the stated maximum.
