ASUS ROG GL704GW-DS76 RAM upgrade specifications
The ASUS ROG Strix GL704GW-DS76 laptop features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum RAM capacity of 32 GB. Compatible memory modules operate at 2666 MHz frequency with SO-DIMM form factor. Upgrade specifications enable users to enhance system performance through compatible DDR4 memory installation in available slots, with maximum capacity supporting up to 32 GB total memory configuration for this specific gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 17 January 2019 |
Additional Notes
- Dual channel architecture requires matching memory modules in both slots to hit peak memory bandwidth for high frame rate gaming on the ASUS ROG GL704GW-DS76.
- The processor memory controller limits speeds to 2666 MHz even if higher rated modules are installed as the motherboard lacks XMP profile support.
- Reaching the maximum capacity of 32 GB necessitates a total replacement of any existing factory modules since all physical slots are occupied in a dual channel configuration.
- Physical installation requires 260 pin modules specifically designed for smaller mobile form factors because standard desktop DIMM hardware is physically incompatible.
- Installing high density 16 GB modules per slot increases thermal output within the chassis during heavy multitasking or intensive rendering tasks.
- The absence of soldered memory on the motherboard allows for a full hardware refresh if a single memory bank suffers a physical failure.
- Latency timings default to the slowest installed module to ensure system stability across diverse hardware batches.
