ASUS ROG GL704GW-EV001 RAM upgrade specifications
ASUS ROG Strix GL704GW-EV001 laptop supports DDR4-SDRAM memory upgrades across two SO-DIMM slots. Maximum compatible RAM capacity reaches 32 GB total. Native memory frequency operates at 2666 MHz. Upgrade specifications indicate support for standard SO-DIMM form factor modules. Compatible memory modules must align with DDR4 specifications for optimal performance and compatibility with the GL704GW-EV001 model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 15 February 2019 |
Additional Notes
- Dual channel architecture requires matching module capacities to optimize memory bus throughput and reduce CPU overhead.
- The 32 GB threshold limits high density virtualization or professional 4K video editing workflows that typically require 64 GB of addressable space.
- Installing modules with speeds exceeding 2666 MHz results in automatic downclocking to the system bus frequency to maintain signal stability.
- Thermal dissipation within the ASUS ROG GL704GW-EV001 chassis relies on specific spatial clearances around the dual SO-DIMM slots which may be impacted by modules featuring thick integrated heat spreaders.
- The utilization of the 2 slots for a maximum configuration prevents further vertical scaling without replacing existing hardware components.
- Storage of volatile data is restricted to the 1.2V DDR4 standard preventing the use of older high voltage DDR3L or DDR3 memory modules due to physical keying and electrical incompatibilities.
- Latency performance is dictated by the slowest installed module in a mixed configuration which can create system wide processing bottlenecks during peak loads.
