ASUS ROG GL704GW-EV011T RAM upgrade specifications
ASUS ROG Strix GL704GW-EV011T laptop supports DDR4-SDRAM memory upgrades with two SO-DIMM slots. Maximum supported capacity reaches 32 GB total, operating at 2666 MHz frequency. Compatible upgrades utilize SO-DIMM form factor specifications. Existing memory configuration allows for expansion through the two available slots to meet performance requirements. Current memory specifications and upgrade pathway documented for system enhancement and compatibility verification.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 25 June 2019 |
Additional Notes
- The ASUS ROG GL704GW-EV011T supports DDR4-2666 memory exclusively, which operates at a lower frequency band than contemporary DDR4-3200 and DDR4-3600 modules. Installing faster-rated memory will downclock to 2666 MHz, resulting in no performance gain while potentially increasing system power consumption.
- Dual SO-DIMM slots create a bottleneck for single-module upgrades. Populating only 1 slot leaves the second unused, preventing dual-channel memory architecture from activating and reducing effective bandwidth by approximately 50 percent compared to matched 2-module configurations.
- The 32 GB ceiling requires both SO-DIMM slots to be occupied with 16 GB modules simultaneously. Upgrading from lower capacities necessitates removing existing modules rather than adding to them, making incremental expansion impossible without discarding the original memory.
- SO-DIMM form factor requires thermal clearance verification near the memory slot area during installation. Laptop chassis designs often position heatsinks or internal components in close proximity, which may obstruct module seating or prevent retention clip operation depending on third-party cooler designs or internal modifications.
- DDR4-2666 availability at retail has declined significantly as manufacturers transitioned to DDR4-3200 and DDR5 production. Sourcing authentic SO-DIMM modules at this frequency specification may require extended lead times or purchasing from surplus/refurbishment channels, potentially affecting warranty coverage.
