ASUS ROG GA401QM-K2023T RAM upgrade specifications
ASUS ROG Zephyrus G GA401QM-K2023T RAM upgrade specifications indicate DDR4-SDRAM memory configuration with one SO-DIMM slot available for expansion. The laptop supports maximum RAM capacity of 32 GB operating at 3200 MHz frequency. Memory architecture features on-board soldered RAM combined with single SO-DIMM slot for upgrading compatible memory modules. Specifications define upgrade potential and compatible memory requirements for this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 28 November 2020 |
Additional Notes
- The ASUS ROG GA401QM-K2023T contains soldered memory on the motherboard, meaning only 1 SO-DIMM slot is available for user replacement or expansion, limiting upgrade flexibility compared to systems with 2 or more slots.
- Adding a single 32 GB SO-DIMM module achieves the 32 GB system maximum, but this configuration creates an asymmetrical memory setup (soldered + 32 GB) that may reduce dual-channel bandwidth efficiency depending on the soldered capacity.
- DDR4-3200 MHz SO-DIMM modules are mature and widely available at reasonable cost, but availability decreases for higher-speed variants (3600+ MHz) in the SO-DIMM form factor, constraining future frequency upgrades within this form factor.
- SO-DIMM installation in gaming laptops requires removal of the bottom panel and thermal management disruption; reinstalling thermal pads or paste over memory modules during access affects thermal performance on subsequent boot cycles until thermal interface material cures.
- 32 GB total capacity suffices for 1440p gaming and multitasking but does not support content creation workflows (4K video editing, 3D rendering) that benefit from 48+ GB in desktop systems with 2 full-size DIMM slots.
- Warranty implications depend on ASUS service policy; opening the chassis for RAM installation may void coverage in certain regions unless performed by authorized technicians, requiring verification before disassembly.
- The single upgrade slot cannot be populated twice; maximum capacity is achieved in a single operation, eliminating the option to upgrade incrementally in 16 GB stages common in multi-slot configurations.
