ASUS ROG GA402RJ-L4179W RAM upgrade specifications
The ASUS ROG Zephyrus G14 GA402RJ-L4179W gaming laptop features DDR5-SDRAM memory upgrade specifications with one SO-DIMM slot for expansion. The system supports maximum RAM capacity of 24 GB, combining on-board memory with upgradeable SO-DIMM modules. Compatible memory operates at 4800 MHz frequency. Upgrade options allow users to expand memory capacity through the available SO-DIMM slot, with specifications supporting DDR5 technology for enhanced performance. The memory configuration accommodates gaming and productivity workload requirements.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 24 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 13 July 2022 |
Additional Notes
- The ASUS ROG GA402RJ-L4179W contains soldered on-board memory paired with a single user-accessible SO-DIMM slot, creating an asymmetrical configuration that limits total capacity to 24 GB despite DDR5 technology.
- DDR5-4800 MHz operation requires compatible SO-DIMM modules rated for this frequency; using slower DDR5 variants will downclock the entire memory subsystem to the module's rated speed, reducing overall bandwidth availability.
- Upgrading beyond the soldered allocation requires a SO-DIMM purchase, but the single slot design eliminates dual-channel configuration options and forces all upgrade capacity into a single module, creating potential latency penalties versus balanced dual-channel layouts.
- The 24 GB ceiling represents an odd-capacity constraint; standard DDR5 SO-DIMM modules ship in 8 GB, 16 GB, or 32 GB denominations, meaning a 16 GB upgrade module will be the only practical option to approach the 24 GB limit without exceeding it.
- SO-DIMM slots typically feature zero-insertion-force retention mechanisms; end-user installation poses minimal mechanical risk and falls within standard warranty coverage for most manufacturers when performed correctly.
- DDR5 SO-DIMM modules remain relatively scarce and command price premiums compared to DDR4 equivalents; supply constraints may restrict module availability or increase acquisition costs beyond traditional upgrade budgets.
