ASUS ROG GU603HM-K8004T RAM upgrade specifications
ASUS ROG Zephyrus M16 GU603HM-K8004T supports DDR4-SDRAM memory upgrade with one SO-DIMM slot available for expansion. The laptop features on-board memory combined with a single upgradeable SO-DIMM slot, allowing maximum RAM capacity of 40 GB. Compatible memory operates at 3200 MHz frequency. Specifications indicate the upgrade slots accommodate DDR4 modules to enhance overall system memory capacity for improved multitasking performance.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 40 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 10 April 2021 |
Additional Notes
- The ASUS ROG GU603HM-K8004T contains soldered on-board memory that cannot be removed, restricting total capacity expansion to the single SO-DIMM slot alone. This architectural choice limits the upgrade ceiling to 40 GB total system memory.
- Installing a 32 GB SO-DIMM module will create an asymmetrical dual-channel configuration, pairing the soldered memory module with the upgradeable SO-DIMM. Performance bandwidth will operate at the speed of the slower module, though both modules function at 3200 MHz to minimize throughput penalties.
- The 3200 MHz frequency specification defines the maximum supported speed for any replacement SO-DIMM module. Modules rated above this frequency will downclock to 3200 MHz, rendering premium higher-frequency modules economically inefficient for this platform.
- SO-DIMM slot compatibility is mechanially and electrically specific to laptop form factors. Replacement modules must conform to DDR4 SO-DIMM dimensions and pinout standards, eliminating desktop DDR4 UDIMM modules as viable alternatives.
- Warranty preservation typically requires components to match manufacturer specifications or carry independent certification. Mixing memory brands or sourcing from third-party sellers may void coverage unless the retailer provides explicit compatibility guarantees aligned with the system's requirements.
