ASUS ROG GU604VY-001W RAM upgrade specifications
ASUS ROG Zephyrus M16 GU604VY-001W laptop supports DDR5-SDRAM memory upgrades through two SO-DIMM slots. The compatible memory specifications include DDR5-4800 MHz modules with maximum capacity of 64 GB total RAM. The upgrade slots accommodate standard SO-DIMM form factor memory modules. These specifications define the compatible memory upgrade options and maximum RAM capacity for this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 18 April 2023 |
Additional Notes
- Dual channel mode requires identical module capacities across both slots to maintain maximum memory bandwidth for the ASUS ROG GU604VY-001W.
- The absence of soldered memory allows for the replacement of both factory modules to reach the 64 GB threshold without capacity asymmetry.
- Installing modules with speeds exceeding 4800 MHz results in automatic downclocking to the system bus limit regardless of the internal XMP or EXPO profiles.
- Total memory capacity is limited by the physical SO-DIMM architecture and BIOS firmware constraints rather than the processor architecture.
- Higher density modules increase thermal density within the RAM seating area which relies on passive airflow for heat dissipation.
- Upgrading to the 64 GB peak requires 2 32 GB modules as the hardware does not support 64 GB single-stick configurations.
- Mixing modules from different manufacturers can lead to timing mismatches and system instability due to variations in CAS latency and sub-timings.
- Installation of non-ECC unbuffered memory is mandatory as buffered or registered server modules are physically and electrically incompatible with the SO-DIMM slots.
