ASUS ROG GX703HS-KF006T-BE RAM upgrade specifications
ASUS ROG Zephyrus S17 model GX703HS-KF006T-BE specifications include DDR4-SDRAM memory upgrade capacity. The laptop features one SO-DIMM slot for RAM expansion, with maximum compatible memory capacity of 48 GB. Memory operates at 3200 MHz frequency. The upgrade configuration consists of on-board memory combined with SO-DIMM slot options. These specifications define the RAM upgrade parameters and memory compatibility for the GX703HS-KF006T-BE gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 48 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 07 October 2021 |
Additional Notes
- The hardware architecture utilizes a hybrid memory configuration combining non-removable soldered chips with a single expansion slot.
- Upgrading the ASUS ROG GX703HS-KF006T-BE to the maximum capacity requires the installation of a 32 GB module to complement the 16 GB fixed on the motherboard.
- Mismatched module capacities will result in an asynchronous dual channel state where only the lower shared capacity operates at full bandwidth.
- Performance fluctuates based on the latency timings of the secondary module because the system defaults to the slowest common denominator between the fixed and removable memory.
- The presence of on-board memory means a total system failure occurs if the soldered chips develop hardware faults since they cannot be swapped.
- Internal access for maintenance involves removing the entire bottom chassis plate which may expose sensitive thermal components or liquid metal compounds.
- Thermal throttling in the memory subsystem is mitigated by the airflow design but remains a factor when high density 32 GB modules are under sustained load.
