ASUS TUF Dash FX517ZC-HN111W RAM upgrade specifications
ASUS TUF Dash F15 series model FX517ZC-HN111W supports DDR5-SDRAM memory upgrades via two SO-DIMM slots. Maximum RAM capacity reaches 32 GB total, with compatible modules operating at 4800 MHz frequency. Memory upgrade specifications indicate SO-DIMM form factor compatibility for this gaming laptop model. RAM expansion slots accommodate dual-channel DDR5 memory configurations, enabling users to enhance system performance through compatible memory module installations.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The presence of 2 physical SO-DIMM slots implies that existing modules must be removed to reach the maximum 32 GB threshold because no memory is soldered to the logic board.
- The 4800 MHz frequency indicates that the **ASUS TUF Dash FX517ZC-HN111W** utilizes a DDR5 voltage of 1.1V which results in improved thermal efficiency compared to older DDR4 hardware.
- Operating 2 identical memory modules activates dual-channel mode which significantly increases memory bandwidth for CPU-intensive tasks and integrated graphics performance.
- Installing modules with a frequency higher than 4800 MHz will result in downclocking to the system bus limit as the BIOS typically lacks XMP support for overclocking profiles.
- The 32 GB limit suggests the motherboard firmware is validated for 16 GB modules per slot despite the processor architecture potentially supporting larger capacities.
- Accessing the memory slots requires removal of the bottom chassis panel which exposes internal components to potential electrostatic discharge risk during the installation process.
