ASUS TUF Gaming FA507NV-LP110W RAM upgrade specifications
The ASUS TUF Gaming A15 FA507NV-LP110W laptop features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 32 GB total RAM. The memory operates at 4800 MHz frequency, providing compatible upgrade options for users seeking enhanced performance. Specifications indicate the system accommodates DDR5 SO-DIMM modules, with each slot supporting up to 16 GB modules for maximum configuration. The upgrade slots allow for flexible memory expansion from factory-installed configurations to the maximum 32 GB capacity.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The ASUS TUF Gaming FA507NV-LP110W contains 2 SO-DIMM slots operating at 4800 MHz, which establishes a hard ceiling of 32 GB total capacity. Expansion beyond this threshold requires complete module replacement rather than additional installation.
- DDR5-4800 modules for this system operate at JEDEC standard frequencies. Third-party modules rated above 4800 MHz will downclock to native specifications, eliminating performance gains from higher-frequency variants and increasing acquisition costs without functional benefit.
- SO-DIMM form factor constrains compatible modules to laptop-specific products. Desktop DDR5 components are physically incompatible and cannot be adapted. Sourcing requires specific laptop memory SKUs rather than standard PC retail options.
- Both memory slots must be populated to achieve maximum theoretical capacity. Single-slot configurations or asymmetrical pairings (such as 8 GB plus 16 GB) will operate at the speed of the slower module, creating a performance bottleneck if mismatched frequencies are installed.
- Dual-channel architecture through 2 slots enables full bandwidth utilization for memory-intensive tasks. Single populated slot forces single-channel operation, reducing effective bandwidth by approximately 50 percent regardless of total capacity installed.
- SO-DIMM modules require removal of bottom panel access covers rather than full keyboard disassembly. This access method typically qualifies as user-serviceable under ASUS warranty policies, though verification with ASUS support prior to installation mitigates documentation disputes post-upgrade.
