ASUS TUF Gaming FA507RR-HN024W-BE RAM upgrade specifications
The ASUS TUF Gaming A15 FA507RR-HN024W-BE laptop features two SO-DIMM memory slots supporting DDR5-SDRAM upgrades. Maximum RAM capacity reaches 32 GB total, with compatible memory operating at 4800 MHz frequency. The upgrade specifications enable users to expand memory in this TUF Gaming Series model by adding or replacing SO-DIMM modules to enhance multitasking performance and system responsiveness.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 January 2022 |
Additional Notes
- The dual slot configuration allows for a symmetrical dual channel architecture which doubles the available memory bandwidth for the processor compared to single module setups.
- The 32 GB ceiling indicates a firmware limitation or a motherboard trace density restriction that prevents the usage of high density 32 GB modules in the ASUS TUF Gaming FA507RR-HN024W-BE.
- Utilizing DDR5 technology necessitates a physical pin alignment and voltage difference that makes this hardware incompatible with all previous DDR4 or DDR3 generations.
- Physical installation requires grounded handling of 262 pin modules to prevent electrostatic discharge damage to the sensitive integrated circuits.
- Latency performance depends on the integrated memory controller within the CPU which dictates the actual command rate regardless of the module speed rating.
- Operating at 4800 MHz requires the system to maintain stable power delivery through the motherboard power phases to ensure data integrity during high load gaming or rendering tasks.
- Internal access for memory replacement typically involves removing the bottom chassis panel which must be done without damaging the heat pipes or the battery connector to maintain factory warranty status.
