ASUS TUF Gaming FA507UV-LP034W RAM upgrade specifications
The ASUS TUF Gaming A15 FA507UV-LP034W supports DDR5-SDRAM memory upgrades with specifications allowing for maximum RAM capacity of 32 GB. The laptop contains 2x SO-DIMM memory slots, compatible with DDR5-SDRAM modules operating at 5600 MHz frequency. Upgrade options are limited to SO-DIMM form factor memory modules. These specifications define the compatible memory upgrade parameters for the FA507UV-LP034W model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5600 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5600 (PC5-44800) |
| Bandwidth | 44.8 GB/s |
Additional Notes
- The ASUS TUF Gaming FA507UV-LP034W contains 2 SO-DIMM slots operating at 5600 MHz DDR5, establishing a maximum addressable capacity of 32 GB total across both modules.
- Single-channel memory configuration occurs if only 1 slot is populated, reducing effective bandwidth by approximately 50% compared to dual-channel operation and causing measurable performance degradation in bandwidth-intensive workloads such as video rendering and data processing tasks.
- DDR5-5600 operates at a higher frequency than DDR4 standards, but bandwidth limitations emerge when paired with high-end GPU configurations; memory latency can become a secondary constraint in frame-rate-dependent scenarios despite raw speed advantages.
- SO-DIMM form factor restricts upgrade sourcing to laptop-specific modules; desktop DDR5 DIMMs are physically incompatible and will not physically insert into the available slots.
- Upgrading beyond the currently installed capacity requires purchasing matched SO-DIMM pairs rated for 5600 MHz DDR5 to maintain dual-channel symmetry; mismatched speeds or capacities may trigger reduced-speed fallback behavior in BIOS.
- The 32 GB ceiling represents a hardware-enforced limit; no firmware update or BIOS modification expands this addressable space beyond what the memory controller physically supports.
- Warranty preservation during RAM upgrades typically remains intact if modules are user-installed without contact with soldered components; adhesive seals on access panels should be documented photographically before removal if warranty claims are anticipated.
