ASUS TUF Gaming FA507XV-LP020W RAM upgrade specifications
The ASUS TUF Gaming A15 FA507XV-LP020W features DDR5-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum RAM capacity of 32 GB total. Compatible memory modules operate at 4800 MHz frequency using SO-DIMM form factor. Upgrade slots accommodate DDR5 memory configurations for enhanced system performance. Specifications indicate dual memory slots allowing modular RAM expansion to reach the maximum supported capacity on this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 April 2023 |
Additional Notes
- The ASUS TUF Gaming FA507XV-LP020W uses DDR5 SO-DIMM modules, which are physically incompatible with DDR4 slots due to different notch positions and voltage requirements.
- The 32 GB maximum capacity limitation is typically enforced by chipset addressing constraints rather than physical slot restrictions, meaning installing larger modules may result in unrecognized memory.
- Both SO-DIMM slots are user-accessible, allowing memory upgrades without violating most manufacturer warranties, though verification of specific warranty terms remains advisable.
- DDR5-4800 represents the JEDEC standard base speed for DDR5, meaning modules rated at higher frequencies will downclock to 4800 MHz unless XMP/EXPO profiles are supported and enabled in BIOS.
- Dual-channel architecture requires matched memory modules in both slots to achieve maximum bandwidth, as asymmetric configurations force single-channel operation with significant performance reduction.
- DDR5 modules incorporate on-die ECC functionality separate from traditional server-grade ECC, providing basic error correction without requiring chipset support.
- Voltage regulation occurs on the DDR5 module itself rather than the motherboard, reducing compatibility issues but requiring modules that meet PMIC specifications for the platform.
- Mixing memory modules with different speeds or timings will cause the system to operate all modules at the lowest common specification, potentially underutilizing faster RAM.
- The 4800 MHz frequency indicates a data transfer rate of 4800 MT/s, delivering theoretical peak bandwidth of approximately 38.4 GB/s per channel in dual-channel configuration.
- SO-DIMM installation requires proper seating at approximately 45-degree angles before pressing down, as improper insertion can damage retention clips or socket contacts.
