ASUS TUF Gaming FX506HCB-HN208T RAM upgrade specifications
ASUS TUF Gaming F15 model FX506HCB-HN208T features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum capacity of 32 GB total RAM. Compatible memory operates at 3200 MHz frequency using SO-DIMM form factor. Upgrade slots accommodate DDR4 modules for enhanced system performance and multitasking capabilities on the gaming laptop platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 07 November 2021 |
Additional Notes
- The dual channel architecture requires identical module pairs to achieve full memory bandwidth and prevent system stuttering during heavy workloads.
- Operating at 3200 MHz on this ASUS TUF Gaming FX506HCB-HN208T depends on the integrated memory controller maintaining stability without downclocking to 2933 MHz or 2666 MHz.
- Physical installation is limited to 260 pin SO-DIMM modules as the hardware lacks support for desktop sized DIMM or soldered LPDDR alternatives.
- Reaching the 32 GB threshold necessitates removing any existing low capacity factory modules since no additional expansion slots exist beyond the 2 provided.
- Upgrading to modules with high density chips may result in boot failure if the BIOS version lacks the necessary firmware updates for modern memory ranks.
- Latency timings should match between both slots to avoid the motherboard defaulting to the slowest Common Denominator JEDEC profile.
- The absence of soldered memory simplifies total replacement of the RAM subsystem in the event of a single module failure after the warranty period.
