ASUS TUF Gaming FX507VI-LP113-GAMING RAM upgrade specifications
The ASUS TUF Gaming F15 series model FX507VI-LP113-GAMING supports DDR5-SDRAM memory upgrades through two SO-DIMM slots. Maximum RAM capacity reaches 32 GB with DDR5-4800 MHz frequency specifications. Memory upgrade compatibility includes standard SO-DIMM form factor modules operating at 4800 MHz frequency. The laptop accommodates DDR5 memory upgrades to achieve maximum 32 GB total capacity across both available slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- The presence of 2 SO-DIMM slots confirms that the ASUS FX507VI-LP113-GAMING utilizes a non-soldered dual-channel memory architecture for improved bandwidth efficiency.
- Upgrading beyond the 32 GB threshold resides outside the manufacturer validated stability range and may result in a failure to boot or system instability.
- Installing modules with a frequency higher than 4800 MHz will result in the hardware downclocking to match the system bus speed limit.
- Balanced performance requires matching module capacities in both slots to ensure the processor operates in full synchronous dual-channel mode.
- Physical access to the memory slots involves removing the base panel which typically requires a Phillips head screwdriver and non-marring prying tools to avoid chassis damage.
- DDR5 modules are not backwards compatible with DDR4 slots due to a different voltage key notch position and signaling protocols.
- The integrated power management circuit on the memory modules shifts voltage regulation from the motherboard to the RAM itself to reduce power waste.
