ASUS TUF Gaming FX507VV-LP243 RAM upgrade specifications
The ASUS TUF Gaming F15 FX507VV-LP243 features DDR5-SDRAM memory upgrade specifications. The laptop contains two SO-DIMM slots compatible with DDR5 modules operating at 4800 MHz. Maximum RAM capacity supports 32 GB total memory configuration. RAM upgrades require SO-DIMM form factor modules. Current memory specifications and upgrade compatibility details are available for the FX507VV-LP243 model within the ASUS TUF Gaming F15 series.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
Additional Notes
- Dual slot architecture confirms that achieving maximum memory capacity necessitates the removal of existing modules if both factory slots are occupied.
- The 4800 MHz frequency indicates a base DDR5 performance tier where installing higher speed modules will result in downclocking to remain within the hardware stability limits.
- Symmetrical memory configurations are required to enable dual channel bandwidth benefits for the ASUS TUF Gaming FX507VV-LP243 integrated controller.
- Physical installation is limited to SO-DIMM form factors which prevents the use of low power soldered memory or desktop sized modules.
- The 32 GB ceiling suggests a firmware or chipset limitation that prevents the utilization of 48 GB or 64 GB high density modules often found in the DDR5 ecosystem.
- Accessing the SO-DIMM slots typically requires the removal of the entire bottom chassis plate which may involve varying screw lengths and plastic clips.
- Latency performance will be governed by the slowest module installed because the system defaults to the highest common JEDEC profile supported by both sticks.
