ASUS TUF Gaming FX607VU-RL141-GAMING RAM upgrade specifications
The ASUS TUF Gaming F16 FX607VU-RL141-GAMING laptop features DDR5-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum capacity of 32 GB. Compatible RAM operates at 5200 MHz frequency using SO-DIMM form factor. Specifications enable memory upgrades to enhance system performance for gaming and professional applications on this TUF Gaming series model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5200 (PC5-41600) |
| Bandwidth | 41.6 GB/s |
Additional Notes
- The presence of 2 SO-DIMM slots allows for a dual-channel memory configuration which significantly increases memory bandwidth compared to single-channel setups.
- Upgrading the ASUS TUF Gaming FX607VU-RL141-GAMING to the 32 GB maximum capacity requires replacing both existing modules if the factory configuration occupies both slots.
- The 5200 MHz frequency rating indicates compatibility with high-speed DDR5 modules but performance remains limited by the processor memory controller capabilities.
- Physical installation requires standard 262-pin SO-DIMM modules as the chassis does not support soldered LPDDR5 memory variants.
- Mixing modules with different timings or densities may force the system to default to the lowest common denominator speed or cause boot failures due to strict DDR5 training requirements.
- The hardware architecture utilizes a 1.1V power delivery system for memory which limits the use of high-voltage overclocking modules without manual BIOS overrides.
- Total system latency is affected by the transition to DDR5 because higher clock speeds are balanced by increased CAS latency relative to older DDR4 standards.
