ASUS TUF Gaming FX706LI-H7117 RAM upgrade specifications
The ASUS TUF Gaming F17 FX706LI-H7117 features two SO-DIMM memory slots supporting DDR4-SDRAM upgrades. The laptop is compatible with memory modules operating at 2933 MHz frequency. Maximum RAM capacity reaches 32 GB, allowing dual-slot configuration with compatible DDR4 modules. Current specifications and upgrade compatibility details enable users to expand system memory for enhanced multitasking and performance capabilities. The SO-DIMM form factor ensures proper fit within the FX706LI-H7117 chassis design.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2933 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2933 (PC4-23464) |
| Bandwidth | 23.5 GB/s |
| Laptop Release date | 20 January 2021 |
Additional Notes
- The dual-slot density limit restricts individual module capacity to 16 GB per socket to maintain system stability within the designated overhead.
- Utilizing two matching modules enables dual-channel memory architecture which significantly increases memory bandwidth for the ASUS TUF Gaming FX706LI-H7117 compared to single-stick configurations.
- Installing modules with higher rated speeds will result in downclocking to the processor-defined 2933 MHz cap because the chipset enforces a strict frequency ceiling.
- Physical access to both SO-DIMM sockets requires removal of the entire base panel which involves navigating plastic clips and internal ribbon cables.
- Latency performance is dictated by the slowest module in the pair necessitating identical CAS latency ratings for optimal timing synchronization.
- System firmware does not support XMP profiles meaning performance hinges on the default JEDEC profiles programmed into the replacement hardware.
