ASUS TUF Gaming FX706LI-HX200 RAM upgrade specifications
The ASUS TUF Gaming F17 FX706LI-HX200 features DDR4-SDRAM memory upgrade capability through 2x SO-DIMM slots. Maximum memory capacity reaches 32 GB. Compatible upgrades utilize SO-DIMM form factor with 2933 MHz frequency specifications. RAM upgrade specifications support dual-channel memory configuration for enhanced performance in gaming and professional applications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2933 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2933 (PC4-23464) |
| Bandwidth | 23.5 GB/s |
| Laptop Release date | 12 August 2021 |
Additional Notes
- The dual channel architecture requires symmetrical module pairs to achieve maximum theoretical memory bandwidth for the ASUS TUF Gaming FX706LI-HX200.
- Installing modules with frequencies exceeding 2933 MHz results in automatic downclocking to match the integrated memory controller hardware limit.
- Upgrading beyond the 32 GB threshold leads to system instability or failure to complete the Power On Self Test due to BIOS firmware addressing limits.
- Occupying both SO-DIMM slots necessitates the removal of existing factory modules because there are no additional vacant expansion points.
- System latency depends on the highest Common Latency value shared between both installed sticks when mixing different memory brands.
- Physical installation requires a non-conductive pry tool to release the bottom chassis clips without compromising the structural integrity of the plastic casing.
- The use of 1.2V DDR4 modules is mandatory to ensure voltage compatibility and prevent thermal throttling within the compact internal cooling environment.
