ASUS Vivobook F412DA-IB31 RAM upgrade specifications
ASUS Vivobook 14 Series F412DA-IB31 laptop supports DDR4-SDRAM memory upgrade specifications. The device features one SO-DIMM slot for RAM expansion. Maximum compatible RAM capacity reaches 12 GB total, combining onboard memory with the upgradeable SO-DIMM slot. Memory operates at 2400 MHz frequency. Upgrade options enable users to expand memory beyond factory configuration for improved multitasking performance and system responsiveness.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 04 September 2019 |
Additional Notes
- The ASUS Vivobook F412DA-IB31 contains soldered memory on the motherboard, creating a fixed baseline capacity that cannot be removed or replaced without board-level repair.
- The 12 GB maximum indicates 4 GB of non-removable soldered RAM paired with the single accessible slot, limiting expansion to an 8 GB module rather than the 16 GB or 32 GB modules commonly available.
- Installing a module faster than 2400 MHz will cause automatic downclocking to match the soldered memory speed, eliminating any performance benefit from higher-rated modules.
- The hybrid memory architecture prevents dual-channel operation across the full capacity, as only the portion matching between soldered and slotted memory runs in dual-channel mode while excess capacity operates in single-channel mode.
- Accessing the single SO-DIMM slot requires complete bottom panel removal, and any such disassembly may void the manufacturer warranty depending on regional service policies.
- The 2400 MHz specification establishes PC4-19200 as the target module standard, though DDR4-2666 modules will function after speed reduction to maintain system stability.
- Systems shipping with less than 12 GB installed leave upgrade headroom, but units already containing 12 GB total have reached their architectural limit with no further expansion possible.
- The SO-DIMM form factor requirement excludes standard desktop DIMM modules, and voltage must remain at the DDR4 standard 1.2V as low-voltage variants may cause compatibility issues with the memory controller.
