ASUS Vivobook N705FD-GC028T RAM upgrade specifications
ASUS Vivobook Pro N705FD-GC028T RAM upgrade specifications indicate DDR4-SDRAM memory compatibility with 2x SO-DIMM slots supporting maximum capacity of 16 GB total. Memory operates at 2400 MHz frequency. Upgrade options accommodate SO-DIMM form factor modules. Compatible memory modules can be installed in available slots to expand system RAM capacity from factory configurations. Maximum memory specifications define the upper limit for RAM expansion on this laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 16 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 02 October 2019 |
Additional Notes
- The ASUS Vivobook N705FD-GC028T uses SO-DIMM slots, which are laptop-specific memory modules that differ from desktop counterparts and require careful handling during installation to avoid damage to the retention clips.
- With 2 memory slots at maximum capacity of 16 GB total, each individual module cannot exceed 8 GB. Asymmetrical configurations (mixing different capacities) will operate at the speed of the slower module, creating potential performance degradation if replacement modules do not match existing frequency specifications.
- The 2400 MHz frequency ceiling indicates this system lacks support for faster DDR4 variants (2666, 2933, 3200 MHz). Installing higher-frequency memory will force automatic downclocking to 2400 MHz, negating any theoretical speed advantage and wasting investment in premium modules.
- SO-DIMM memory carries tighter physical tolerances than full-size DIMMs. The compact form factor leaves minimal clearance around slot edges, meaning certain heatspreader designs on aftermarket modules may obstruct keyboard mechanisms or adjacent components during reinsertion.
- Warranty implications exist depending on manufacturer policy. Opening the chassis to access memory slots may void coverage unless the design includes user-accessible panels explicitly identified in documentation as field-serviceable areas.
- Future expansion beyond 16 GB is impossible without replacing existing modules entirely, as this represents the architectural maximum for the motherboard's memory controller.
