HP Elitebook Folio 1040 G2 RAM upgrade specifications
HP Elitebook Folio 1040 G2 RAM upgrade specifications indicate DDR3L-SDRAM memory compatibility. The laptop features 1x SO-DIMM slot for memory expansion. Maximum supported capacity reaches 8 GB, operating at 1600 MHz frequency. Compatible memory modules use SO-DIMM form factor. Upgrade options allow single-slot configuration for increased performance and multitasking capability.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR3L-SDRAM |
| Frequency | 1600 MHz |
| Maximum RAM | 8 GB |
| Voltage | 1.35V (Low Voltage) |
| Number of pins | 204-pin |
| Interface | PC3L |
| PC Speed Rating | PC3L-1600 (PC3L-12800) |
| Bandwidth | 12.8 GB/s |
Additional Notes
- The presence of a single expansion slot in the HP Elitebook Folio 1040 G2 necessitates the replacement of the existing module rather than the addition of a second one for memory increases.
- System architecture restricts the memory interface to single channel operation regardless of the module capacity installed.
- Hardware voltage requirements mandate the use of 1.35V modules to ensure post-initialization stability and avoid motherboard power delivery failures.
- Integrated graphics performance remains limited by the 1600 MHz bandwidth ceiling of the system bus.
- Memory modules exceeding the 8 GB threshold will likely result in a failure to boot due to BIOS and chipset addressing limitations.
- The internal physical clearance prevents the installation of modules equipped with tall integrated heat spreaders.
- Standard DDR3 1.5V modules are incompatible and may cause thermal damage to the memory controller if forced into the slot.
