HP Probook 440 G6 (x5) RAM upgrade specifications
HP Probook 440 G6 (x5) RAM upgrade specifications include two SO-DIMM memory slots supporting DDR4-SDRAM memory modules. Maximum RAM capacity reaches 32 GB total. Compatible memory operates at 2400 MHz frequency. Upgrade options accommodate SO-DIMM form factor modules. Specifications define memory expansion capabilities for the HP Probook 400 series model 440 G6 (x5).
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 31 July 2020 |
Additional Notes
- Dual channel architecture is achievable only when both SO-DIMM slots are populated with matching modules, which doubles the theoretical memory bandwidth compared to a single stick configuration.
- The HP Probook 440 G6 motherboard utilizes a 260 pin physical interface for internal memory expansions.
- Installing modules with frequencies higher than 2400 MHz will result in a downclocking effect to match the system bus speed, providing no performance gain over standard specifications.
- The chipset architecture limits total addressable memory to 16 GB per slot, preventing the use of higher density 32 GB single sticks.
- Full capacity utilization requires a 64 bit operating system to manage the hardware addressing space beyond the 4 GB threshold.
- Accessing the memory slots involves removing the bottom base cover, which serves as the primary thermal dissipation surface for the internal components.
- Integrated graphics performance scales directly with the speed and configuration of the installed RAM since the system shares a single memory pool for both processing and video tasks.
