HP Probook 445R G6 (x5) RAM upgrade specifications

HP Probook 400 Series 445R G6 (x5) laptop memory upgrade specifications include DDR4-SDRAM compatibility with 2x SO-DIMM slots supporting maximum RAM capacity of 32 GB. The upgrade specifications detail SO-DIMM form factor memory modules operating at 2400 MHz frequency. Compatible RAM upgrades for the 445R G6 (x5) model accommodate DDR4-SDRAM memory expansion to achieve maximum specifications of 32 GB total capacity across the available memory slots.

Additional Notes

• The HP ProBook 445R G6 (x5) accepts only SO-DIMM modules, which excludes standard desktop DIMM memory and requires laptop-specific components during upgrades.
• The 32 GB maximum capacity enforces a configuration constraint where both slots must be populated with 16 GB modules to reach full potential, leaving no intermediate upgrade path beyond dual 8 GB installations.
• The system's 2400 MHz frequency ceiling will downclock any faster modules to this speed, making higher-frequency DDR4-3200 purchases functionally identical to standard 2400 MHz variants while potentially incurring unnecessary cost.
• Dual-channel architecture depends on identical module pairing across both slots, as mismatched capacities or speeds force operation in single-channel mode with measurable bandwidth reduction.
• DDR4-2400 SO-DIMM voltage typically operates at 1.2V, and non-standard low-voltage variants may cause POST failures or intermittent stability issues despite physical compatibility.
• Unbuffered non-ECC SO-DIMM modules represent the compatible specification, as registered or error-correcting memory architectures will trigger incompatibility errors on consumer-grade chipsets.
• The SO-DIMM 260-pin form factor prevents installation of older DDR3L modules despite superficial slot similarity, protecting against voltage mismatch damage but requiring verification before purchase.
• Single-rank versus dual-rank module topology affects memory controller efficiency differently, with some configurations exhibiting marginal latency variations under identical capacity and frequency specifications.
• Warranty preservation typically requires avoiding chassis disassembly beyond user-accessible panels, making verification of bottom-case memory door access critical before attempting field upgrades.
• Module height clearance beneath the keyboard assembly limits compatibility to standard SO-DIMM profiles, potentially excluding specialty low-profile or heat-spreader-equipped variants despite electrical compatibility.
