HP Probook 450 G10 RAM upgrade specifications
HP Probook 450 G10 RAM upgrade specifications include two SO-DIMM memory slots supporting DDR4-SDRAM modules operating at 3200 MHz frequency. The laptop accommodates a maximum RAM capacity of 32 GB total memory. Compatible upgrades utilize SO-DIMM form factor modules. The specifications define the upgrade slots and maximum memory configuration supported by the HP Probook 450 G10 model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 01 April 2023 |
Additional Notes
- Dual channel architecture requires matching memory modules to reach maximum bus bandwidth and prevent memory controller downclocking.
- The presence of 2 physical slots in the HP Probook 450 G10 allows for a symmetrical memory configuration that optimizes integrated graphics performance compared to single channel setups.
- Installation of modules exceeding 3200 MHz results in automatic downclocking to the system bus limit determined by the processor architecture.
- Upgrading to the maximum capacity necessitates the removal of existing modules if both slots are occupied from the factory.
- Mixing modules with different latencies forces the system to operate at the timings of the slowest installed stick.
- The SO-DIMM form factor implies a tool based internal access requirement where static discharge precautions are necessary to avoid motherboard damage.
- Maintaining original factory modules is recommended if warranty claims require the device to be returned in its original hardware state.
- The 32 GB ceiling indicates a hardware limitation in the BIOS or motherboard traces that prevents the utilization of 32 GB single sticks for a 64 GB total.
