HP Probook 450 G6 (3x 5PP62EA) RAM upgrade specifications
HP ProBook 450 G6 (3x 5PP62EA) laptop supports DDR4-SDRAM memory upgrades with two SO-DIMM slots. Maximum RAM capacity reaches 32 GB total. Compatible memory operates at 2400 MHz frequency. Upgrade specifications indicate SO-DIMM form factor for RAM modules. Current configuration includes three units of model 5PP62EA, with expansion capability through available memory slots for enhanced system performance and multitasking capacity.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 20 April 2019 |
Additional Notes
- Dual channel architecture requires matching module capacities in both slots of the HP ProBook 450 G6 (3x 5PP62EA) to optimize memory bandwidth and improve integrated graphics performance.
- The hardware architecture supports higher frequency modules like 2666 or 3200 MHz but will downclock them to the system limit of 2400 MHz due to chipset constraints.
- Population of both physical SO-DIMM slots is necessary to bypass the latency penalties associated with single channel configurations.
- Reaching the 32 GB maximum threshold requires the installation of 2 individual 16 GB modules as the motherboard does not support high density 32 GB single sticks.
- Internal access for memory replacement requires the removal of the entire base panel which involves navigating plastic clips and internal cable routing.
- The use of standard voltage 1.2V DDR4 is required as the system is not designed for older low voltage DDR3L or high voltage overclocked gaming memory.
- Installing asynchronous memory capacities will trigger Intel Flex Memory Technology where only the matched portion of the RAM operates in high speed dual channel mode.
