MSI Bravo 17 A4DDK-002XES RAM upgrade specifications
MSI Bravo 17 A4DDK-002XES laptop features two SO-DIMM slots supporting DDR4-SDRAM memory upgrade specifications. Maximum compatible RAM capacity reaches 64 GB total. Memory operates at 3200 MHz frequency. Upgrade specifications indicate SO-DIMM form factor modules are compatible with this model. Current memory slots allow expansion of existing RAM configuration to meet performance requirements.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 07 March 2020 |
Additional Notes
- The dual channel architecture requires symmetrical pair installation to achieve peak memory bandwidth and prevent processor bottlenecks in the MSI Bravo 17 A4DDK-002XES.
- Upgrading to the 64 GB maximum requires removing all pre-installed modules because the motherboard lacks additional vacant slots.
- The integrated graphics system shares the system RAM, meaning higher capacity modules directly increase the available video memory buffer for rendering tasks.
- Physical installation is limited to 260 pin modules due to the SO-DIMM form factor constraint which is incompatible with desktop DIMM hardware.
- Latency timings should match between modules to prevent the system from downclocking to the slowest common denominator or failing the POST sequence.
- High density 32 GB sticks must be unbuffered and non-ECC to ensure motherboard firmware compatibility during the boot process.
- Thermal management within the chassis relies on passive cooling for the memory, so modules with thick integrated heat spreaders may cause fitment issues under the bottom panel.
