MSI Creator A10SF-039FR RAM upgrade specifications

MSI A10SF-039FR MSI A10SF-039FR MSI A10SF-039FR MSI A10SF-039FR MSI A10SF-039FR

MSI Creator 15 A10SF-039FR laptop features DDR4-SDRAM memory upgrade specifications. The system contains 2x SO-DIMM slots supporting maximum RAM capacity of 64 GB. Compatible memory modules operate at 2666 MHz frequency with SO-DIMM form factor. RAM upgrade slots allow installation of additional memory to enhance system performance. Maximum specifications enable up to 64 GB total memory capacity for this MSI Creator series laptop model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date25 August 2020

Additional Notes

  • Dual channel memory architecture requires installing a matching pair of modules to maximize the available memory bandwidth for rendering tasks.
  • The MSI Creator A10SF-039FR motherboard architecture lacks support for XMP profiles, meaning higher speed modules will downclock to the native system frequency.
  • Accessing the internal hardware requires the removal of the entire bottom chassis cover, which may involve penetrating a factory seal sticker applied over a screw hole.
  • Physical clearance within the slim chassis restricts the use of memory modules equipped with thick integrated heat spreaders.
  • The 64 GB maximum capacity is achieved by utilizing 32 GB high density modules in both physical sockets.
  • Lower latency memory kits with CL15 or CL16 timings provide a measurable performance increase in creative applications despite the 2666 MHz hardware limitation.
  • The use of standard 1.2V DDR4 modules is necessary as the system firmware does not provide voltage adjustment for high performance overvolted RAM.
