MSI Cyborg 15 A12VF-040 RAM upgrade specifications

MSI 15 A12VF-040 MSI 15 A12VF-040 MSI 15 A12VF-040 MSI 15 A12VF-040 MSI 15 A12VF-040

The MSI Cyborg 15 A12VF-040 laptop features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 64 GB. Compatible RAM operates at 4800 MHz frequency. Upgrade options accommodate DDR5 memory modules in SO-DIMM form factor. The specifications define maximum supported memory configuration for this MSI 15 series model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR5-SDRAM
Frequency4800 MHz
Maximum RAM64 GB
Voltage1.1V
Number of pins262-pin
InterfacePC5
PC Speed RatingPC5-4800 (PC5-38400)
Bandwidth38.4 GB/s
Laptop Release date16 February 2023

Additional Notes

  • Dual channel architecture requires matching module pairs to maximize memory bus throughput and prevent single channel bandwidth bottlenecks.
  • The presence of 2 physical slots implies that reaching the 64 GB maximum requires the removal and replacement of any preinstalled modules.
  • The MSI Cyborg 15 A12VF-040 utilizes DDR5 technology which operates at lower voltage than DDR4, reducing thermal output within the chassis during heavy memory loads.
  • Motherboard firmware constraints will downclock high performance 5200 MHz or 5600 MHz modules to the 4800 MHz ceiling supported by the system architecture.
  • Upgrade procedures involve internal access which necessitates breaking the factory seal, potentially affecting warranty status depending on regional consumer protection laws.
  • Internal motherboard layout requires 1.1V SO-DIMM modules as high voltage XMP profiles are typically unsupported in this bios environment.
  • Capacity expansion beyond the 64 GB limit is restricted by the processor integrated memory controller and physical slot density limitations.
