MSI Gaming GE63 8SF-030ES Raider RGB RAM upgrade specifications

MSI GE63 8SF-030ES Raider RGB MSI GE63 8SF-030ES Raider RGB MSI GE63 8SF-030ES Raider RGB MSI GE63 8SF-030ES Raider RGB MSI GE63 8SF-030ES Raider RGB

The MSI GE63 8SF-030ES Raider RGB Gaming Series laptop features DDR4-SDRAM memory upgrade specifications. The device includes 2x SO-DIMM slots for RAM expansion, supporting a maximum capacity of 32 GB total memory. Compatible upgrades operate at 2666 MHz frequency with SO-DIMM form factor. Specifications enable memory expansion for enhanced multitasking and performance capabilities on the MSI GE Gaming Series platform.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date10 January 2019

Additional Notes

  • Dual channel architecture requires matching memory modules in both slots to reach theoretical peak bandwidth.
  • Physical access to the motherboard necessitates removal of the entire bottom chassis cover.
  • The 32 GB ceiling is an addressing limit of the chipset or firmware that prevents the use of 32 GB individual modules.
  • Installing modules with frequencies exceeding 2666 MHz results in automatic downclocking to the clock speed defined by the system BIOS.
  • Memory latency remains governed by the slower of the 2 installed modules when mixing different brands.
  • Voiding of the warranty occurs in certain regions if the factory seal over the chassis screws is broken during the installation process.
  • Thermal constraints from adjacent GPU and CPU heat pipes require low profile modules without thick integrated heat spreaders.
  • The SO DIMM configuration precludes the use of standard desktop DIMM hardware due to voltage and pin count differences.
