MSI Gaming GF65 9SEXR-801XIT Thin RAM upgrade specifications

MSI GF65 9SEXR-801XIT Thin MSI GF65 9SEXR-801XIT Thin MSI GF65 9SEXR-801XIT Thin MSI GF65 9SEXR-801XIT Thin MSI GF65 9SEXR-801XIT Thin

MSI GF65 9SEXR-801XIT Thin gaming laptop supports DDR4-SDRAM memory upgrades. The system features 2x SO-DIMM slots with maximum RAM capacity of 64 GB. Compatible memory modules operate at 2666 MHz frequency using SO-DIMM form factor. Upgrade specifications allow installation of DDR4 memory modules in both available slots to enhance system performance and multitasking capabilities.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date23 June 2020

Additional Notes

  • Full utilization of the 64 GB capacity requires the physical removal of existing pre installed modules due to the dual slot architecture limitation.
  • The MSI GF65 9SEXR-801XIT Thin utilizes a dual channel configuration that mandates paired module installation to maximize memory bus bandwidth.
  • Installing memory modules with frequencies exceeding 2666 MHz results in automatic downclocking to match the native motherboard chipset limitations.
  • System stability depends on the use of unbuffered non ECC hardware because the consumer grade mobile chipset lacks parity bit error correction support.
  • Accessing the SO-DIMM slots involves the removal of the entire bottom chassis panel which may impact certain regional warranty seals depending on local service policies.
  • High density 32 GB modules must adhere to the standard 1.2V JEDEC profile to ensure compatibility with the factory BIOS power delivery settings.
  • Physical clearance within the compact chassis restricts memory upgrades to standard height SO-DIMM modules without integrated bulky heat spreaders.
