MSI Gaming GF75 10SDR-234 RAM upgrade specifications

MSI GF75 10SDR-234 MSI GF75 10SDR-234 MSI GF75 10SDR-234 MSI GF75 10SDR-234 MSI GF75 10SDR-234

MSI GF75 10SDR-234 gaming laptop RAM upgrade specifications include two SO-DIMM memory slots supporting DDR4-SDRAM modules. Compatible memory operates at 2666 MHz frequency. Maximum RAM capacity reaches 64 GB total when both slots are populated. Upgrade specifications detail supported memory types and slot configurations for this MSI Gaming GF series model.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date07 May 2020

Additional Notes

  • The presence of 2 SO-DIMM slots implies that reaching maximum capacity requires the removal of all factory-installed modules to accommodate 2 32 GB sticks.
  • The MSI GF75 10SDR-234 motherboard architecture limits memory speed to 2666 MHz, meaning higher frequency modules will automatically downclock to match the system bus latency.
  • Operating 2 identical memory modules enables dual-channel mode, which significantly increases memory bandwidth compared to single-stick configurations.
  • Upgrading memory requires the removal of the entire bottom chassis panel, which may involve breaking a factory seal sticker in certain regions.
  • Maximum 64 GB support ensures the hardware remains compatible with heavy virtualization and professional video editing workloads that exceed standard gaming requirements.
  • The use of DDR4 technology necessitates 1.2V small outline modules, as high-voltage desktop memory or older DDR3 hardware will not fit the physical notch alignment.
