MSI Gaming GF75 8RD-008 RAM upgrade specifications
MSI GF75 8RD-008 gaming laptop supports DDR4-SDRAM memory upgrades. The system features two SO-DIMM slots with maximum capacity of 32 GB total RAM. Compatible memory operates at 2666 MHz frequency. Upgrade specifications indicate support for SO-DIMM form factor modules. The GF series gaming model can accommodate memory expansion up to the maximum supported capacity through the available slots. DDR4-SDRAM specifications provide technical compatibility parameters for memory upgrade configuration.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 10 November 2018 |
Additional Notes
- Dual channel memory architecture requires installing matching modules in both available slots to maximize memory controller bandwidth.
- The MSI GF75 8RD-008 motherboard architecture limits hardware addressing to 16 GB per slot, preventing the use of higher density 32 GB single sticks.
- Installing memory modules with speeds exceeding 2666 MHz results in automatic downclocking to match the hardcoded frequency limit of the chipset.
- Accessing the SO-DIMM slots requires the removal of the entire bottom chassis panel, which involves breaking a factory seal sticker in some regional jurisdictions.
- The physical clearance within the thin chassis profile necessitates the use of standard height SO-DIMM modules without integrated thick heat spreaders.
- Mixing modules with different latency timings forces the system to operate at the slower JEDEC profile of the two installed components.
- Upgrading from a single module to a dual module configuration significantly reduces integrated graphics bottlenecks and improves frame time consistency in CPU bound scenarios.
