MSI Gaming GL63 8SDK RAM upgrade specifications
MSI GL63 8SDK gaming laptop supports DDR4-SDRAM memory upgrades with two SO-DIMM slots. Maximum RAM capacity reaches 32 GB total. Compatible memory modules operate at 2666 MHz frequency. Specifications indicate upgrade potential from factory configuration through dual-channel slot architecture. Memory form factor standardizes SO-DIMM dimensions for MSI GL Series gaming systems. RAM upgrade specifications define compatible memory types and maximum expandable capacity for GL63 8SDK models.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 10 June 2019 |
Additional Notes
- Dual channel architecture requires matching module pairs to utilize the full memory controller bus width.
- The 2666 MHz clock speed serves as a hardware ceiling where higher rated modules downclock to match the system bus.
- Upgrading the MSI GL63 8SDK to the 32 GB limit necessitates replacing any existing pre installed modules due to the lack of additional vacant slots.
- Total memory capacity is constrained by the 8th Generation Intel architecture which governs the maximum addressable space per slot.
- Accessing the SO-DIMM slots requires removal of the entire bottom chassis panel which may involve breaking a factory seal sticker.
- Voltage requirements for the DDR4-SDRAM conform to 1.2V standards and prohibit the use of older high voltage memory modules.
- Latency timings on replacement sticks must be compatible with the embedded BIOS profiles to ensure system stability during heavy workloads.
